Underwater Ikelite Housing Sony ZV-1 II Digital Camera

A full featured and durable underwater housing for Sony ZV-1 Mark II Digital Camera. Suitable for scuba, snorkel, surf, pool, and any application in or around the water.

Specifications

Controls	Controls for all camera functions except touch panel; Wind screen is not usable inside of the housing
Strobe Connector	Optional TTL Converter
Lens Port	7.62 cms Diameter with 67mm Threads
Accessory Port	1/2-20 Thread
Depth Rating	60 meters (200 feet)
Weight	1.17 kg
Dimensions	173 x 127 x 137 mm (6.8 x 5 x 5.4" )
Rear O-Ring	0109

Construction

Ikelite specially formulated ABS-PC blend housing is highly durable yet lightweight for travel. The light color keeps your camera cooler when shooting in warm, sunny environments.

Lens Support

• The WD-3 Wide Angle Dome provides mid-range angle of view with no vignetting (dark shadows in the corners of the image).
• The INON UWL-H100 # 64310, W-30 Wide Angle Lens # 6430, and other 67mm threaded wide angle lenses, provide a wider maximum angle of view. Because these are separated from the camera's lens by glass, air, and water, some vignetting and edge distortion will be present. These effects can be reduced or eliminated by using a smaller aperture, zooming in slightly, and/or cropping in post-production.
• External macro lenses with 67mm threads including the INON UCL-165 M67 # 64312, Subsee, Nauticam, Epoque, and other manufacturers, can be attached directly to the front of the housing's port.

Flash Option

Most Ikelite DS strobes can be triggered with manual and TTL exposure by using the DL2 DS Link Sony TTL Converter Ikelite ST1 Hotshoe and B1A Bulkhead Kit # 46045 and a compatible sync cord. Our Sony TTL conversion circuitry works beautifully for both macro and wide angle photography. The DS Link features a push button to switch back and forth between TTL and manual on the fly.

Wi-Fi Transfer

Use the camera's built-in Wi-Fi feature to download photos to another device without removing the camera from the housing. The Wi-Fi feature is only usable above water within close proximity to the connected device.

Compatibility

Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories. Differences in lens and control placement prevent other camera models from being used in or adapted to this housing. Ikelite is not aware of any other models which may be used in or adapted to this housing.

In the Box

• Housing
• Rear o-ring # 0109 (installed)
• Vinyl port cover # 0200 (installed)
• Silicone lubricant 1cc tube
