AOI GoPro Underwater Close-Up Lens
AOI GoPro Underwater Close-Up Lens
Enhance your underwater photography with the AOI UCL-03 Underwater Close-up Lens. Designed for action cameras like GoPro and smartphones, this lens provides a 90° underwater angle of coverage, allowing you to capture stunning close-up shots with ease. The lens construction consists of 3 elements in 3 groups, ensuring high-quality images with minimal distortion. All lens elements are made of optical glass and housed in a durable hard-anodized aluminum alloy barrel, providing both optical clarity and robustness. With a focus distance ranging from 40mm to 78mm underwater, the AOI UCL-03 offers versatility in capturing subjects of various sizes and distances. The lens mount utilizes the AOI Quick Release System-02 (QRS-02), making it compatible with the most popular AD mounts. Whether you're an avid underwater photographer or a casual enthusiast, the AOI UCL-03 is an essential accessory for capturing detailed close-up shots of marine life and underwater scenes.
Specifications
- Model: AOI UCL-03
- Description: Underwater Close-up Lens for Action Camera & Phone
- Lens Construction: 3 Elements in 3 Groups
- Material: All Lens Elements in Optical Glass, Lens Barrel in Hard Anodized Aluminum Alloy, Silicone Front Bumper Ring
- Lens Coating: All Glass Lens Elements with Multi-layers AR Coating
- Field of View (Underwater): 90 Degree
- Focus Distance (Underwater): 40mm (min.) to 78mm (max.) from the front lens element to the Subject
- Lens Mount: Using AOI Quick Release System-02 (QRS-02), Lens pre-installed with QR2 Mount (Compatible with the most popular AD Mount)
- Optional Lens Mounts: AD-M55-UWL-03 Adapter for UCL-03 with M55 Thread Mount, AD-M52-UCL-03 Adapter for UCL-03 with M52 Thread Mount
- Depth Rating: 60 Meters / 200 Ft.
- Dimensions: Φ81mm(D) x 28.5mm(H)
- Weight: On Land: 181 g, Underwater: 175 g
- Standard Accessories: Neoprene Front Lens Cap, Rear Lens Cap in QR2 Mount, Lens Pouch (AOI LPC-01), Lens Secure Line (AOI QRL)
Adapter & Cable Compatibility
- Compatible with specified adapters (see description).
In the Box
- AOI GoPro Close-Up Lens
- Neoprene Front Lens Cap
- Rear Lens Cap in QR2 Mount
- Lens Pouch (AOI LPC-01)
- Lens Secure Line (AOI QRL)
