AOI UH-EM10IV Olympus EM-10 IV Housing for Olympus OM-D E-M10 Mark IV Camera

Product Details

The AOI UH-EM10IV housing accommodates the Olympus OM-D E-M10 Mark IV mirrorless camera. This housing is supplied with a Flat Port (AOI-FLP-06) and Lens Gear Ring (AOI-LG-OM-1442EZ) to accommodate the Olympus OM-D E-M10 Mark IV with the Olympus 14-42mm EZ lens.

Other compatible Olympus lenses can be used with the appropriate AOI/Olympus PEN Mount Port and Extension.

The AOI UH-EM10IV housing is compatible with AOI Ports & Extension Rings for PEN mount housings. This high-quality underwater housing is lightweight and ergonomic with all the camera controls accessible and at your fingertips. It is made of polycarbonate with a depth rating of 45 meters (150ft).

To trigger external strobes this housing is supplied with the AOI Hot Shoe (AOI-HSC-02) which connects to the camera hot shoe and via a fibre optic cable (cable not included) will trigger underwater strobes from AOI, Sea&Sea, Ikelite, Inon etc. (available separately) If you wish to use the Olympus RC Flash Mode for perfect camera controlled exposed images the AOI UCS-Q1RC Ultra Compact Strobe or Olympus UFL-03 Strobe is required.

Best of all this housing has a built-in vacuum monitoring & wet detection system to safeguard your investment. It also comes with a spare M16 bulkhead.

Housing Overview

Why compromise when you can have it all? The AOI UH-EM10IV Housing for Olympus OM-D E-M10 Mark IV camera enables you to get more out of your underwater photo system than ever before and for a great price! It’s rugged and durable yet lightweight and compact. With extra vacuum protection and a leak detector, it’s practical, yet ergonomic and stylish. This housing is as easy to handle as a point-and-shoot camera and yet packed with extra features to enable pro-level photography. Want even more? Add one of many accessories offered by AOI to enhance your UH-EM10IV housing and meet your photography needs. Camera and Lens not included.

Housing Features

Durable, shock-resistant design
Depth rated to 45 meters (150 ft)
Lightweight and compact
Extra protection with a Vacuum Analyzation and Wet Detection System (VWS) and secure lock
Advanced ergonomics allow use even with gloves, an extended shutter release lever is included to make the trigger easier to use when using a base tray with a handle.
Clearly marked controls allow full access to essential camera functions.
Full accessory package available: Compatible with most common underwater housing accessories using these connection points: 1/4” tripod thread, cold shoe mount, LCD monitor hood rails, lanyard loops, 67mm lens port thread, QRS slots and fibre optic cable ports.
An optical flash trigger is built-in to trigger external strobes which saves camera battery life.
The housing platform gives you the option to grow as your skills do: Explore advanced possibilities with dedicated camera lenses and AOI’s PEN Mount type lens ports using the UH-EM10IV housing interchangeable lens port design.

Specifications

MODEL NUMBER	AOI UH-EM10 IV
DESCRIPTION	Underwater Housing for Olympus E-M10 IV - Black Colour
HOUSING COLOUR	AOI UH-EM10 IV-WHT	AOI UH-EM10 IV-BLK
	White	Black
COMPATIBLE CAMERA MODELS	Olympus OM-D E-M10 Mark IV
MAIN MATERIAL	Housing Body: Polycarbonate
DEPTH RATING	45 Meters
LENS PORT SYSTEM	AOI / Olympus PEN Ports System
BUILT-IN LED FLASH TRIGGER	Compatible with a) Manual Flash Trigger (with and without Pre-flashes Functions) b) Olympus RC Mode (TTL AUTO, MANUAL, FP TTL AUTO, FP MANUAL)
WATER LEAKAGE PROTECTION	Built-in Vacuum Analyzation and Wet Detection System (VWS)
BATTERY POWER	Built-in Rechargeable Lithium Polymer Battery (3.7V 110mAH)
BATTERY CHARGING	By USB Charger DC5V, 0.5A (not included) Approx. 1.5 hours for a full charge
BATTERY OPERATION TIME	Approx. 2 Days (Based on 3 Dives/Day and 1 Hour/Dive)
DIMENSIONS	177.9mm (W) x 139.8mm (H) x 151.2mm (D)
WEIGHT	On Land: Approx.835 g (Only included the Housing Body and Flat Port)
STANDARD ACCESSORIES	Flat Port (AOI FLP-06); Lens Gear (AOI LG-OM-1442EZ)
	Hot Shoe Connector (AOI HSC-02); USB Type-C Charging Cable (AOI USBC-02)
	Vacuum Pump (AOI VP-02); LCD Monitor Hood (LCDH-01)
	Spare O-Ring for Vacuum Valve Protection Cap x 1pc. (AOI SRVV-01)
	Spare Main Seal O-ring x 1pc. (AOI HOR-01)
	Silica Gel (AOI SIGE-3) x 1pc.; Silicone Grease (AOI SIGR-5)
	Lanyard (AOI LYD-01); Port Front Cap for M67 Thread (AOI LFC-01)
	Port Rear Cap for PEN Mount (AOI PRC-02); O-ring Remover (AOI ORR-02)
	Micro-Fibre Cleaning Cloth (AOI MC-01); AOI Logo Sticker
